Tank trucks:

Tank trucks: also known as mobile fuel trucks, computer tax control fuel trucks, tank trucks, loading trucks, tank trucks, edible oil tank trucks, mainly used for the transportation and storage of petroleum derivatives (gasoline, diesel, crude oil, lubricating oil, coal tar and other oil products).According to different uses and use environments, there are various refueling or conveying functions, including oil suction, pumping, and various oil separation and oil dispensing functions. The special part of the oil truck is composed of tank, power take-off, drive shaft, gear oil pump, pipe network system and other components. The pipeline system is composed of oil pump, three-way four-position ball valve, two-way ball valve, filter screen, pipeline, etc.
  • Tank trucks:
  • Tank trucks:
  • Tank trucks:
  • Tank trucks:
  • Tank trucks:

Description

Vehicle parameters
General Vehicle model ZLC5120GJYEQ6
Chassis brand Dongfeng
Overall dimensions (mm) 7020×2350,2200×2850
Gross weight (kg) 11990
Rated payload(kg) 6740/6675
Curb weight(kg) 5120
Chassis parameters
Taxi Driver's seat 2
Drive type 4*2
Engine Fuel type Diesel
Engine model YCF25160-66
Engine Brand YUCHAI
Power (kW/hp)
Emission standards Euro 3/4/5
Chassis Wheelbase (mm) 3800
Tire specifications 245/70R19.5
Oil tank structural parameters
Storage tank volume(m³) 10
Tank thickness 5 mm
Oil pump Single tank pump with overflow valve 76-40
