Chassis
|
Chassis brand |
JAC |
|
Overall dimensions (mm) |
5995 × 2010 × 2700 |
|
|
Gross weight (kg) |
4495 |
|
|
Driver's seat |
2 |
|
|
Drive type |
4*2 |
|
|
Fuel type |
Diesel |
|
|
Engine Brand |
Yunnei |
|
|
Power (kW/hp) |
103/140 |
|
|
Emission standards |
Euro 6 |
|
|
Wheelbase (mm) |
2850 |
|
|
Tire specifications |
6.50R16 |
|
|
Color |
Customer's request |
|
|
Upper body configuration
|
Platform Working Height （m） |
28 |
|
Boom type |
7 section boom (6 section synchronous telescopic) |
|
|
Outrigger |
4 pcs, Lateral span of outrigger 5100mm |
|
|
Bucket |
1600×650×1150 mm(LWH), 200kg load |
|
|
Slewing device |
Two-way 360° continuous slewing, 360°slewing basket |
|
|
Operating system |
Up and down operation both on ground and in bucket, Wireless remote control + platform operation + manual 3 groups of operating |
|
|
Emergency device |
Yes |
Height for work at height:
8 meters, 10 meters, 12 meters, 14 meters, 16 meters, 18 meters, 20 meters, 22 meters, 24 meters25 meters,
26 meters, 27 meters, 28 meters, 30 meters, 32 meters, 34 meters, 36 meters, 38 meters
Key structural components such as telescopic booms, turntables and frames are all welded from low-alloy high-strength steel, featuring high strength and light weight, and have been fully verified through various tests.
