Product Parameters
|
Truck Specification |
|
|
Cab |
Single row cab , with power steering. Electronic flameout |
|
Driving Type |
4*2 Left hand driving |
|
Max Speed (km/h) |
100Km/h |
|
Overall dimension(mm) |
9200*2660*4000 |
|
GVW( kg) |
18000 |
|
Curb weight(Kg) |
|
|
Payload(Kg) |
|
|
Tire |
275/80R22.5 18PR |
|
Steering |
Hydraulic steering with power assistance |
|
Chassis |
|
|
Fuel Type |
Diesel |
|
Enging |
YCS06290-61 |
|
Power(hp) |
290 |
|
Wheelbase(mm) |
5100 |
|
Gear box |
10-speed |
|
Type |
Straight line four cylinder turbocharging |
|
Exhaust(ml) |
6100mL |
|
Braking system |
|
|
Service Brake |
Spring energy |
|
Park Brake |
Wedge brake |
|
Auxiliary brake |
24v |
|
Upper-Body specification |
|
|
Material of van box |
In the middle of Polyurethenefoam, Inner and coating is glass fiber |
|
Thickness of van box (mm) |
80mm Polyurethene foam |
|
Model of Refrigeration unit |
China |
|
Van box dimension(mm) |
6800×2440×2500mm |
|
Length of van (m) |
9-12 |
|
Capacity of van (m³) |
42m³ |
|
Mini temperature in van (ºC) |
-18(suitable for transfer food ) |
