Tank trucks

Tank trucks: also known as mobile fuel trucks, computer tax control fuel trucks, tank trucks, loading trucks, tank trucks, edible oil tank trucks, mainly used for the transportation and storage of petroleum derivatives (gasoline, diesel, crude oil, lubricating oil, coal tar and other oil products).According to different uses and use environments, there are various refueling or conveying functions, including oil suction, pumping, and various oil separation and oil dispensing functions. The special part of the oil truck is composed of tank, power take-off, drive shaft, gear oil pump, pipe network system and other components. The pipeline system is composed of oil pump, three-way four-position ball valve, two-way ball valve, filter screen, pipeline, etc.
  • Tank trucks
  • Tank trucks
  • Tank trucks
  • Tank trucks
  • Tank trucks

Description

Vehicle parameters
General Car brands Liwei
Chassis brand JAC
Overall dimensions (mm) 5850×2100×2750
Gross weight (kg) 9100
Rated payload(kg) 5070
Curb weight(kg) 3835
Chassis parameters
Taxi Driver's seat
Drive type 4*2
Engine Fuel type Diesel
Engine model YCF25160-66A
Engine Brand Yuchai
Power (kW/hp) 116/160
Emission standards Euro 3/4/5
Chassis Wheelbase (mm) 3365
Tire specifications 7.50R16LT 16PR
Oil tank structural parameters
Storage tank volume(m³) 7.6
Tank thickness 5mm
Oil pump Single tank pump with overflow valve 76-40
Medium tank Gasoline
