Product Parameters
|
Truck Specification |
|
|
Product name |
Fire truck |
|
Overall dimension(mm) |
5550*1950*1980 |
|
Drive type |
4x4 left hand drive |
|
Gross weight(Kg) |
4105 |
|
Payload(Kg) |
1800 |
|
Curb weight(Kg) |
2530 |
|
Cab seats |
2 |
|
Wheelbase(mm) |
3110 |
|
Chassis |
|
|
Chassis model |
FOTON |
|
Cab |
Single row, ABS, manual windows, fabric seats |
|
Emission standard |
Euro 3/4/5 |
|
Fuel type |
Diesel |
|
Tyre specification |
LT265/65R17 |
|
Engine model |
4F25TC4 |
|
Power(hp) |
160 |
|
Transmission |
6gear |
|
Exhaust(ml) |
2500mL |
|
Upper-Body specification |
|
|
Fire pump model |
CB10/30 |
|
Fire Monitor Range(m) |
More Than 55m |
|
Rated flow/pressure |
30L/s @1.0MPa |
